Chapter 4 Setup Software
60
4
4.4.3 Saving updated settings in a file
1. Click the [Save] button. The “Save Settings file” screen appears.
2. Click in the file name entry field and enter a file name.
Up to 8 characters can be used for a file name.
3. Click the [OK] button.
•
If the entered file name is illegal, an error message appears and the file is
not saved.
In this case, click the [OK] button and repeat steps 1 to 3.
➮ See page 67.
•
If the file is properly saved, the following message appears.
Reference: If a file saved with a name consisting of only alphanumerics (alphabets
and numbers) is sent to the BL-600 Series, the file name is also sent. In this case,
when you read the settings of the BL-600 Series the next time, you can also read
the file name to check the name of the current file of the BL-600 Series. This is
convenient for maintenance.
If characters other than alphanumerics are included in a file name, the file name is
not sent to the BL-600 Series because the BL-600 Series cannot recognize them.
[OK] button Click [Cancel] to return to the
previous screen.
Click the [OK] button to return to the
initial screen.
