133
Chapter 8 PLC Link
8
■ Setting SYSMAC-C Series
1. Set the RS-232C communication parameters (baud rate, data length, parity and
stop bit length) according to the BL-600’s settings.
2. Set the unit number according to the BL-600’s setting.
3. Set the command level to “Level 1, 2, 3”.
4. Set “1:1/1:N” to “1:N”.
5. Set “I/O port” to either “RS-232C” or “RS-422A”.
6. Set “Trigger input” to “Internal”.
7. Set “Supply 5 V” to “Disable”.
8. Set “CTS” to “0 V (Normally ON).”
* The “I/O port”, “Trigger input”, “Supply 5 V” and “CTS” parameters may not be
provided depending on the type of link unit.
* If using the C200HE/HG/HX or a communication board, follow steps 1 and 2
above, and set the mode to “Upper link”, and “CTS control” to “None”. Use the
initial settings for the other parameters.
■ Setting KV Series/handheld programmer port
1. The KV series’ RS-232C port must always be set to the following values:
• Baud rate : 9600 bps
• Data length: 8 bits
• Parity: Even
• Stop bit length: 1 bit
2. Set the RS-232C communication parameters of the BL-600 according to the
above settings. Set the BL-600’s communication mode to “KV”.
* No other parameters need to be set.
■ Settings for KV-L2/KV mode*
1. Set the KV-L2’s communication mode to “KV mode”.
Set the BL-600’s communication mode to “KV”.
2. The KV mode must be always set to the following values:
• Baud rate : 9600 bps
• Data length: 8 bits
• Parity: Even
• Stop bit length: 1 bit
Set the RS-232C communication parameters of the BL-600 according to the
above settings.
3. Set the station number to “00”.
4. To use the KV-L2 port 2, set the port 2 selector switch to “RS-232C” or "RS-
422A".
* No other parameters need to be set.
Note: KV-L2 is not available in Europe.
