Chapter 4 Setup Software
68
4
/ / / New setting data [Untitled] / / /
< < Model = BL-600 > > [x] Selected
[_] -----------
=> Changed
1) Main
[Read mode] [x] Single [_] Multi 1 [_] Multi 2 [_] Multi 3
[Data-send] [x] After read [_] At trigger input
[Repeat-reading time] [10] x 100 ms
[Decoding match count] [2] times
[Read error] ERROR [4552524F52]
[Add Decoding match count] [_] Enable
[Add scan count] [_] Enable
[Add code type] [_] Enable
[Add label orientation] [_] Enable
[Add symbology ID.] [_] Enable
[Add PMI.] [_] Enable
2) Trigger setup
[Signal type] [x] Level [_] One shot
[One shot input time] [10] x 100 ms
[Input time] [x] 2 ms [_] 10 ms
[State] [x] Normally open [_] Normally close
[Command for Trigger ON] LON [4C4F4E]
[Command for Trigger OFF] LOFF [4C4F4646]
[Test mode initiated with input ON] [x] OFF [_] Reading-rate check [_] Tact check
[Test mode initiated upon power-up] [x] OFF [_] Reading-rate check [_] Tact check
[Power-on trigger] [_] Enable
3) Comm Settings–1
[Baud rate] 9600 bps.
[data bits] [x] 7 bits [_] 8 bits
[Parity] [x] Even [_] Odd [_] None
[Stop bits] [x] 1 bit [_] 2 bits
[RTS/CTS] [_] Use RTS/CTS handshaking
[Multi-drop link(RS-485)] [_] Enable
[ID number] No. [1]
4) Comm Settings–2
[Use PLC] [_] Enable
[Handshaking] [x] None [_] PASS/RTRY [_] ACK/NAK
[Header] [x] None [_] STX [_] ESC [_] Custom
[Delimiter] [x] CR [_] CR+LF [_] ETX [_] Custom
[Partition mark] : [3A]
[Intermediate delimiter] , [2C]
[Checksum] [_] Enable
[Send delay time] [0] ms
5) Utility
[Stability LED] [_] Use stability LED
[OK/NG output duration] [50] x 10 ms
[Preset data] = [no data]
[Reverse bar code reading]
[_] Enable
[Quiet zone scale] [7] Times
[Decode cancel count] [0]
[Test SW output] [x] Enable
(1/2)
4.7 Example of Printing from the Setup Software
When “Print” is executed from the setup software, the following data is printed.
