In addition to the common features described previously, some of the Device Windows also contain
device‑specific features that are described below.
AllFrame
The Device Overview for the F6 Modular I/O Frame, which is part of the AllFrame Multi‑Modular I/O System
(displayed on screen simply as AllFrame) shows which optional I/O cards have been installed into each of
its six card slots.
The AllFrame I/O Card table displays the installed cards for each AllFrame.
