Firmware Update Window Menus
When the Firmware Update window is open the following menu commands are available:
File Menu
Print Opens the standard Windows OS printer selection dialog box and
allows you to print a report showing the current firmware versions for all
devices in the network (shortcut ‑ Ctrl+P)
Close Window Closes the Firmware Update window (shortcut ‑ Ctrl+W)
Firmware Report
Printing a firmware update report provides a written record of the network’s current firmware revisions.
Firmware Update
Control Master: 6416dio
Clock Master: 6416dio
Network Mode: Auto
Clock Mode: Internal
Network Sample Rate: 48kHz
Firmware Bootloader
Device Location Version CRC Version CRC
6416dio #1 3.42 F689 0.24 7B25
6416i #1 STAGE 3.42 7FBD 1.23 33F1
6416m #1 STAGE 3.42 A860 1.04 4B2E
6416o #1 FOH 3.42 7FBD 1.23 33F1
MH10f #1 FOH 3.42 B546 1.13 33C0
MH10f 2.25 C2C3 1.13 33C0
Aviom Firmware Update Report June 30, 2010
Page 1 of 1
Sample content from a firmware report
Update Options Menu
Locate Update Files Opens a dialog box that allows you to navigate the computer’s hard
disks to locate the folder where the firmware update files are stored. Use
this to choose a firmware update folder other than the default.
Refresh Update
Files
This command refreshes the Firmware Update window view and should
be used if the devices in the network or the contents of the firmware
update files folder changes while the Firmware Update window is open.
Use Default Update
Files
Select this command to reset the location of the firmware updates files
back to the default.
