Aviom Pro64 Network Manager - Manual (Page 152)

143 P
ro
64 N
etwork
M
aNager
U
ser
g
Uide
F
F6 Modular I/O Frame 2, 21, 24, 72
Fab Four 104
Failed Devices 31
File Menu
Device Window 115, 130
Firmware Update 33
Network Overview 61
Workspace 49
Filter
Device Type 57
Network Overview 57
reset 58
Slot Range 60
Uncheck All 58
Filter Dialog Box 58
Filter On 58
Filter Settings 57, 58, 60, 62, 136
project 58
Finish button 31
Firmware 2, 5, 33
roll back 20, 35
Firmware Report 33
firmware roll back 36
Firmware Update 14, 20, 21, 35
6416Y2 26, 83
cancel 32
default location 35
m‑control 85
Print report 33
time remaining 32
Firmware Update Fails 31
firmware update file 12
Firmware Update Utility 29, 30
Firmware Update Window
close 32
firmware version 30
folder 39, 122
project 38, 39
Scene, Device Preset 38
folders 12
Front Panel DIP Switches
6416Y2 card 25
front panel LED flashing 62
Front Panel Lock 55
FTDI USB Driver 12
G
Gain 100, 112, 117
gain range 90
garden gnome 98
gimme back
that filet o’ fish 112
GPIO 133, 134
gray Status icon 75, 77
green channel LED 70
green LED icon 133
green OK 124
Grids 65
H
Hardware Standby 79
Hardware Standby Active 79, 80
Help
mono, PMC 1255 51
Help Menu
Workspace 51
Hub 93
I
ID 46
in 38
incompatible device 36
Input Assignments 70
input module
stereo link 99
Input/Output Grids 65
Inputs and Outputs 116
Inputs Assigned to Slot 121
Input Slot Range 52, 53
Inputs to Network 64, 66, 68, 89, 98, 111, 116
Installation Location 9
Installing Pro64 Network Manager 6
install location, default 12
Internal Clock 46, 80, 94
invalid Scene 128
I/O Card 72
AllFrame 72, 112
I/O Grid 65
AllFrame 66
I/O routing 18, 119
L
Labels 59
LED Device Identify 54, 62
clear 55
LED flashing
front panel 62
LED icon 133
License 8
Link a Channel Pair 99
Locate Update Files 33
Location 30, 38, 52, 58, 59, 122
Lock All Front Panels 55
Lock All Scenes 127, 131
Lock Column
Scene 124
Locked Scene 123, 125, 126
Lock Front Panel 55, 116
lock icon 55, 116
Locking a Scene 126
Lock Scene 127, 131
Lock/Unlock
