Channel Settings Menu – Input Devices
The Channel Settings menu is available for I/O modules only (AllFrame, 6416i, 6416m, 6416Y2, 6416dio, and
6416o) and contains the commands listed below.
Input Module Settings (AllFrame, 6416i, 6416m, 6416Y2, and 6416dio)
Activate Input Channel Makes the selected channel active in the network and lights its
green ‘Active’ LED.
Activate All Input
Channels
Sets all channels of the current device as active in the network and
lights their green ‘Active’ LEDs.
Deactivate Input
Channel
Deactivates the selected channel, removing it from the network,
and turns off its green ‘Active’ LED.
Deactivate All Input
Channels
Deactivates all channels on the device, removing them from the
network, and turns off all green ‘Active’ LEDs.
Stereo Link On Activates a stereo link for a pair of adjacent channels.
Stereo Link Off Clears the Stereo Link for the selected channels.
Clear Input Channel
Name
Clears text from the Channel Name field.
Clear All Input Channel
Names
Clears text from the Channel Name field of all 16 channels.
Clear Channel Settings AllFrame and 6416m only; clears the channel strip parameters
(Mute, Gain, Phase, Low Cut, Pad, +48V) for the selected channel.
Clear All Channel
Settings
AllFrame and 6416m only; clears all channel strip parameters (Mute,
Gain, Phase, Low Cut, Pad, +48V).
Clear All Input Matrix
Slot Assignments
Resets an input device to the default routings.
P N
ote
Activating one or more input channels on a Pro64 input module is subject to all Auto Mode
network rules. Attempting to activate an input module’s channel into a network Slot that is
already in use by another input device will result in an error message.
