Rockwell Automation Publication CHPS-UM001D-EN-P - July 2014

85

Rockwell Automation Publication CHPS-UM001D-EN-P - July 2014

85

Appendix

B

Accessories

Interconnect Cables

Power Cable Dimensions (catalog number 2090-XXNPMF-16Sxx)

The maximum cable length of 10 m (32.8 ft).

1 Bend radius (BR) is the specified minimum bend radius for cable assemblies. For standard cable, BR is a one-time flex

application. Flex cables have a much higher BR to withstand flex applications. BR can vary on user-fabricated cables.

Topic

Page

Interconnect Cables

85

Installation, Maintenance, and Replacement Kits

87

14.0 (0.55)

28.0 (1.1)

75 (2.9)

75 (2.9)

142 (5.59)

BR+
BR-

Dimensions are in mm (in.)

Start of Bend Radius

Cable Shield

(overall)

Connector

Diameter

Cable

Diameter

Bend Radius1

Brown

Black

Blue

Green/Yellow

Cable Shield

(for brake wires, not used for linear motor stages)

A

B

C

E

H F G

L

A

B

C

F

G

E

H

L

16 AWG BROWN

16 AWG BLACK

16 AWG BLUE

16 AWG GRN/YEL

18 AWG WHITE

18 AWG BLACK

18 AWG WHITE

18 AWG RED

U

V

W

BR+

BR -

1

2

SHIELD

Pin

Gauge

Color

Signal Designation

A

16

Brown

U

B

16

Black

V

C

16

Blue

W

GND

16

Green/Yellow

GND
