Rockwell Automation Publication CHPS-UM001D-EN-P - July 2014 59
Chapter
9
Maintenance
Before You Begin The following tools are required to lubricate and clean your stage.
• 0.5 m (14 in.) or larger clamp with soft jaws.
• Grease (catalog number MPAS-CART).
• Grease gun kit (catalog number MPAS-GPUMP) with tip type installed
and primed.
• Air line with maximum pressure of 10 psi.
• Lint free cloth.
• A few drops of isopropyl alcohol if necessary for cleaning encoder scale.
Topic Page
Before You Begin 59
Lubricate the Bearing 60
Optical Encoder Scale Maintenance 60
Strip Seal Cleaning 61
Cover Cleaning 61
IMPORTANT Any person that teaches, operates, maintains, or repairs these stages must be
trained and demonstrate the competence to safely perform the assigned task.
ATTENTION: Lockout tagout power before servicing.
