72

Rockwell Automation Publication CHPS-UM001D-EN-P - July 2014

Appendix A Specifications and Dimensions

Table 9 - Performance Specifications for 200 mm frame size CHPS-Series Linear Stages

Performance Specifications for 250 mm frame size CHPS-Series Linear Stages

Cat. No.

Slide Mass

Continuous

(1)(2)

Peak Maximum

Static
Load

(3)

Max Static Moment Loads

(3)

Current Thrust

Current

Thrust

Pitch

Yaw

Roll

kg (lb)

A rms (Ao-pk)

N (lbf)

A rms (Ao-pk)

N (lbf)

kN (lbf)

kN (lbf)

N•m (ft•lb)

N•m (ft•lb)

CHPS-x8xxxD-xLMxxx

5.64 (12.4)

3.1 (4.3)

132 (30)

8.3 (11.7)

302 (68)

66 (14836)

171 9126)

412 (304)

270 (199)

CHPS-x8xxxE-xLMxxx

8.34 (18.4)

6.2 (8.7)

265 (60)

16.5 (23.3)

600 (135)

66 (14836)

270 (199)

620 (457)

270 (199)

CHPS-x8xxxF-xLMxxx

8.34 (18.4)

3.1 (4.3)

265 (60)

8.2 (11.6)

600 (135)

66 (14836)

270 (199)

620 (457)

270 (199)

(1) Measured at 20 °C (68 °F) ambient.
(2) For covered and sealed stages derate by 10%.
(3) Values apply to bearing rating only. Contact Applications Engineering for structural considerations.

Cat. No.

Slide Mass

Continuous

(1)(2)

Peak Maximum

Static Load

(3)

Max Static Moment Loads

(3)

Current Thrust

Current

Thrust

Pitch

Yaw

Roll

kg (lb)

A rms (Ao-pk)

N (lbf)

A rms (Ao-pk)

N (lbf)

kN (lbf)

kN (lbf)

N•m (ft•lb)

N•m (ft•lb)

CHPS-x9xxxJ-xLMxxx

11.54 (25.4)

3.0 (4.2)

385 (87)

8.1 (11.5)

882 (198)

93.6 (21042)

170 (125)

385 (283)

508 (375)

CHPS-x9xxxK-xLMxxx

9.69 (21.4)

3.0 (4.2)

193 (43)

8.1 (11.5)

441 (99)

93.6 (21042)

324 (239)

734 (541)

508 (375)

CHPS-x9xxxL-xLMxxx

11.54 (25.4)

6.0 (8.5)

385 (87)

16.2 (22.9)

882 (198)

93.6 (21042)

324 (541)

734 (541)

508 (375)

(1) Measured at 20 °C (68 °F) ambient.
(2) For covered and sealed stages derate by 10%.
(3) Values apply to bearing rating only. Contact Applications Engineering for structural considerations.
