Rockwell Automation Publication CHPS-UM001D-EN-P - July 2014

61

Maintenance

Chapter 9

Strip Seal Cleaning

Clean the strip seals, if installed, by using a lint free cloth lightly saturated with
isopropyl alcohol

Refer to the

Strip Seal Removal

procedure on page

65

and

Strip Seal

Replacement

procedure on page

66

when performing this task.

Cover Cleaning

Clean the covers at the same time you clean the strip seals. Use pressurized air and
a lint free cloth lightly saturated with isopropyl alcohol to remove any dirt or
grease.

IMPORTANT

Replace the strip seal if it cannot be cleaned, or if an uneven or scored surface is
detected during cleaning.

A buildup of foreign material on the strip seal degrades the performance of the
linear stage. This buildup coupled with rapid movement of the slide and the
resulting friction can score the surface and create a burnished appearance on
the strip seal

Elements contributing to a typical buildup on the strip seals are dust, grease,
and other contaminates normally encountered in any operating environment
that is not strictly controlled.
