Rockwell Automation Publication CHPS-UM001D-EN-P - July 2014 69
Appendix
A
Specifications and Dimensions
This appendix is a supplement to this document. Associated Kinetix publications
listed in
Additional Resources on page 9 and information in product
specifications can supersede the information in this appendix.
Topic Page
Static and Static Moment Loads 70
Performance Specifications for 325V CHPS-Series Stage 70
Performance Specifications for 325V or 650V CHPS-Series Stage 71
Accuracy Specification for the CHPS-Series Stage 73
General Stage Specifications 73
Commutation Sensor 73
Limit Sensor Specification 73
PTC Thermistor Specifications 73
Encoder Specifications 74
Maximum Velocity for Allen-Bradley Drives 74
Environmental Specifications for CHPS-Series Stages 75
CHPS-Series Stage Travel versus Weight Specifications 75
CHPS-Series Stage Dimensions 77
CHPS-Series Stage Technical Specifications 83
