Rockwell Automation Publication CHPS-UM001D-EN-P - July 2014 83
Specifications and Dimensions Appendix A
CHPS-Series Stage Technical
Specifications
Use this specification to make stage dependent calculations.
Cat. No. Total Moving
Mass Coil Resistance (p - p) Force Constant
@25 °C (77 °F) @100 °C (212 °F)
kg (lb) Ohms Ohms N/A
0 - peak
(lbf/A
0 - peak
)
CHPS-A6xxxA-xLMxxx 5.39 (11.85) 7.2 9.3 24.1 (5.42)
CHPS-A6xxxB-xLMxxx 7.09 (15.6) 3.6 4.6 24.1 (5.42)
CHPS-A6xxxC-xLMxxx 7.09 (15.6) 14.3 18.6 48.2 (10.83)
CHPS-A8xxxA-xLMxxx 6.70 (14.73) 7.2 9.3 24.1 (5.42)
CHPS-A8xxxB-xLMxxx 8.87 (19.52) 3.6 4.6 24.1 (5.42)
CHPS-A8xxxC-xLMxxx 8.87 (19.52) 14.3 18.6 48.2 (10.83)
CHPS-x8xxxD-xLMxxx 7.57 (16.65) 3.8 4.9 30.3 (6.81)
CHPS-x8xxxE-xLMxxx 10.23 (22.5) 1.9 2.4 30.3 (6.81)
CHPS-x8xxxF-xLMxxx 10.23 (22.5) 7.5 9.8 60.7 (13.64)
CHPS-A9xxxG-xLMxxx 8.56 (18.84) 9.4 12.2 40.2 (9.04)
CHPS-A9xxxH-xLMxxx 10.70 (23.53) 4.7 6.1 40.2 (9.04)
CHPS-A9xxxI-xLMxxx 10.70 (23.53) 18.8 24.5 80.4 (18.07)
CHPS-x9xxxJ-xLMxxx 10.02 (22.04) 4.9 6.4 45.5 (10.29)
CHPS-x9xxxK-xLMxxx 13.16 (28.95) 2.5 3.2 45.5 (10.29)
CHPS-x9xxxL-xLMxxx 13.16 (28.95) 9.9 12.8 91.0 (20.46)
