82 Rockwell Automation Publication CHPS-UM001D-EN-P - July 2014
Appendix A Specifications and Dimensions
Figure 25 - CHPS-x9xxxH/I/K/L-xLMxxx
25.4
(1.0)
Slide
339
(13.35)
130.8
(5.15)
104
(4.09)
265.7
(10.46)
116
(4.58)
Ø 5.8 (0.23) Thru
Ø 9.7 (0.38) Thru
14.2 (0.56)
120
(4.72)
30.0
(1.18)
105.4
(4.15)
(4X) M8 x 1.25-6H
(4X)
Ø 6.8 (0.27)
12.0 (0.47)
45.2 (1.78) Thru
264.7
(10.42)
208.6
(8.21)
28.0
(1.10)
281
(11.06)
338.14
(13.31) 46.8
(1.84)
8.5
(0.33)
38.3
(1.51)
172.2
(6.78)
249
(9.8)
5.6
(0.22)
25.4
(1.0)
55.4
(2.18)
25.4 (1.0)
Mechanical Overtravel
440.6
(17.35)
+ Travel
Bracket located ±51 (2.0)
from center of travel.
Ground Screw
M5 x 0.8-6H
25.4 (1.0)
Mechanical Overtravel
Detail A
(2X) Ø 5.5 (0.22) Thru
Pilot Hole
120 (4.72)
Toe Clamp/T-Nut Spacing
See Detail A
6.5 (0.26)
Depth, max
Toe Clamp is standard for
covered stages. Mount to base
using M6 x1.0 socket cap screw.
T-Nut
Mount to base using M6 x 1.0 hardware
(optional accessory).
(4X) 9/16-12 UNC Thru (2 per end cap)
Access point for lubricating linear bearings.
Provision to use lifting hooks (not provided).
Travel
Travel Length mm (in.)
Shortest 80 (3.15)
Increments 60 (2.36)
Longest 1580 (62.2)
