Rockwell Automation Publication CHPS-UM001D-EN-P - July 2014 25
Chapter
4
Mounting the Stage
Unpacking, Handling, and
Inspection Inspect packaging to make certain no damage occurred in shipment. Document
any damage or suspected damage. Claims for damage due to shipment are usually
made against the transportation company. If you suspect damage, contact
Rockwell Automation immediately for further advice.
Be sure the information listed on the purchase order correlates to the information
on the packing slip for your stage and its accessories.
Topic Page
Unpacking, Handling, and Inspection 25
Unpacking Procedure 26
Store Packaging Material 28
Stage Storage 28
Mounting the Stage 28
Before You Begin the Mechanical Installation 28
Determine the Number of Fasteners Required 28
Determine the Type of Fastener to Use 29
Mounting the Stage 31
Mount Your Application 32
IMPORTANT Any person that teaches, operates, maintains, or repairs these stages must
be trained and demonstrate the competence to safely perform the assigned
task.
