70

Rockwell Automation Publication 2097-UM001D-EN-P - November 2012

Chapter 4

Connecting the Kinetix 300 Drive System

Wire the Input Power (IPD) Connector

Table 27 - Input Power (IPD) Connector

L3

L2

L1

PE

L3

L2

L1

L2/N

L1

N

PE

L2/N

L1

N

L2

L1

PE

L2

L1

Kinetix 300 Drive

Top View

Drive Cat. No.

Terminals

Recommended
Wire Size
mm

2

(AWG)

Strip Length
mm (in.)

Torque Value
N•m (lb•in)

2097-V31PR0
2097-V32PR0
2097-V32PR2
2097-V33PR1
2097-V33PR3
2097-V34PR3
2097-V34PR5
2097-V34PR6

L3
L2
L1
PE

(1)

L2/N
L1
N
PE

(2)

L2
L1
PE

(3)

2.5 (14)

7 (0.28)

0.5 (4.5)

2097-V32PR4
2097-V33PR5

4.0 (12)

7 (0.28)

0.5 (4.5)

2097-V31PR2
2097-V33PR6

6.0 (10)

7 (0.28)

0.56…0.79
(5.0…7.0)

(1) Applies to 2097-V33PRx, and 2097-V34PRx drive modules.
(2) Applies to 2097-V31PRx drive modules.
(3) Applies to 2097-V32PRx drive modules.
