Rockwell Automation 2097-Vxxx Kinetix 300 EtherNet/IP Indexing Servo Drive User Manual User Manual
Page 67
Rockwell Automation Publication 2097-UM001D-EN-P - November 2012
67
Connecting the Kinetix 300 Drive System
Chapter 4
Table 25 - Shunt Resistor Power Wiring Requirements
ATTENTION: To avoid personal injury and/or equipment damage, make sure
installation complies with specifications regarding wire types, conductor sizes,
branch circuit protection, and disconnect devices. The National Electrical Code
(NEC) and local codes outline provisions for safely installing electrical
equipment.
To avoid personal injury and/or equipment damage, make sure motor power
connectors are used for connection purposes only. Do not use them to turn the unit
on and off.
To avoid personal injury and/or equipment damage, make sure shielded power
cables are grounded to prevent potentially high voltages on the shield.
Accessory
Description
Connects to
Terminals
Recommended Wire
Size
mm
2
(AWG)
Torque Value
N•m (lb•in)
2097-Rx
Shunt Resistor
+
2.5 (14)
0.5 (4.5)
SH
