Rockwell Automation 1755-OF8 GuardPLC Controller Systems User Manual
Page 67

Publication 1753-UM001C-EN-P - March 2010
67
Wire the GuardPLC 2000 Controller and I/O Chapter 5
There are 4 reference poles for the 8 outputs. A pair of outputs share
a reference pole as shown below.
Each group of 2 outputs is electrically isolated from the others.
These outputs
Share these Reference Poles
1 and 2
O1- and O2-
3 and 4
O3- and O4-
5 and 6
O5- and O6-
7 and 8
O7- and O8-
IMPORTANT
If an unused channel is defined as a current output (software
configuration set to current output), the output channel has to
be short-circuited. Place jumpers into these outputs and tighten
the screws.
IMPORTANT
If an unused channel is defined as a voltage output (software
configuration set to voltage output), the unused outputs must be
left open. Short-circuiting a unused voltage output may cause
damage to the output.
Terminal Number
Designation
Function
1
O1+
Analog output 1
2
O1-
Group 1 reference pole
3
O2+
Analog output 2
4
O2-
Group 1 reference pole
5
O3+
Analog output 3
6
O3-
Group 2 reference pole
7
O4+
Analog output 4
8
O4-
Group 2 reference pole
9
shield connection
signal ground
10
O5+
Analog output 5
11
O5-
Group 3 reference pole
12
O6+
Analog output 6
13
O6-
Group 3 reference pole
14
O7+
Analog output 7
15
O7-
Group 4 reference pole
16
O8+
Analog output 8
17
O8-
Group 4 reference pole
18
shield connection
signal ground
RUN ERR
1755-
OF8
1
2
3
4
5
6
7
8
9
O1-
O2+
O2-
O3+
O4+
10
11
12
13
14
15
16
17
18
O1+
O3-
O4-
O5-
O6+
O6-
O7+
O8+
O5+
O7-
O8-
