66
Publication 1753-UM001C-EN-P - March 2010
Chapter 5 Wire the GuardPLC 2000 Controller and I/O
Wire the 1755-IF8 Analog
Input Module
This module features 8 single-ended analog inputs or 4 differential
analog inputs. Two-wire or four-wire transmitters can be used. The
devices cannot be powered from the GuardPLC module. An external
power supply is required for all analog transmitters. Single-ended
transmitters connect between the Ix
+ and I- terminals. For example:
pins 1 and 2, 3 and 4, 5 and 6. Differential transmitters connect
between Ix+ and x- terminals. For example, pins 1 and 10, 3 and 12, 5
and 14.
All reference poles (I-) are internally connected.
Wire the 1755-OF8 Analog
Output Module
This module features 8 analog outputs. Devices cannot be powered
from the 1755-OF8 module. An external power supply is required for
all analog output devices.
IMPORTANT
Unused channels must be short-circuited. See page
Terminal Number
Designation
Function
1
I1+
Analog input 1
2
I-
Reference pole for input 1
3
I2+
Analog input 2
4
I-
Reference pole for input 2
5
I3+
Analog input 3
6
I-
Reference pole for input 3
7
I4+
Analog input 4
8
I-
Reference pole for input 4
9
shield connection
signal ground
10
I5+/1-
Analog input 5
11
I-
Reference pole for input 5
12
I6/2-
Analog input 6
13
I-
Reference pole for input 6
14
I7+/3-
Analog input 7
15
I-
Reference pole for input 7
16
I8+/4-
Analog input 8
17
I-
Reference pole for input 8
18
shield connection
signal ground
RUN ERR
1755-
IF8
1
2
3
4
5
6
7
8
9
I-
I2+
I-
I3+
I-
I4+
I-
10
11
12
13
14
15
16
17
18
I1+
I-
I6+/2-
I-
I7+/3-
I-
I8+/4-
I-
I5+/1-
