Publication 1753-UM001C-EN-P - March 2010 57
Wire GuardPLC 1600, GuardPLC 1800, and GuardPLC 1200 Controllers Chapter 4
The analog inputs are connected to these terminals.
Terminal Number Designation Function
41 T1 Transmitter supply 1
42 I1 Analog input 1
43 L- Reference pole
44 T2 Transmitter supply 2
45 I2 Analog input 2
46 L- Reference pole
47 T3 Transmitter supply 3
48 I3 Analog input 3
49 L- Reference pole
50 T4 Transmitter supply 4
51 I4 Analog input 4
52 L- Reference pole
53 T5 Transmitter supply 5
54 I5 Analog input 5
55 L- Reference pole
56 T6 Transmitter supply 6
57 I6 Analog input 6
58 L- Reference pole
59 T7 Transmitter supply 7
60 I7 Analog input 7
61 L- Reference pole
62 T8 Transmitter supply 8
63 I8 Analog input 8
64 L- Reference pole
