Chapter
14
Use the Control Panel to Monitor Status
Introduction The Control Panel is your window into the online functionality of the
controller. Use the tabs to modify or monitor controller status.
Topic Page
Resource State Tab 124
Safety Parameters Tab 125
Statistics Tab 126
P2P (Peer-to-Peer) State Tab 127
Distributed I/O Tab 128
HH (High-level High-speed) State Tab 128
Environment Data Tab 129
OS Tab 129
HSP Protocol Tab 130
EIP Protocol Tab 131
Use the Multi Control Panel 132
Control Panel Resource Menu 135
Control Panel Extra Menu 136
