In the previous figure:
•
In Drive A, links were established between the function block
control application and the drive I/O parameters.
Channel A of Drive A is connected to four 1/4 rack adapters by
daisy chaining a single blue hose. By setting up Drive A in
scanner mode, Drive A can act as a master device and the 1/4
rack adapters can act as slave devices.
•
Drive B is connected to Drive A using Drive–to–Drive
communications via a DeviceNet cable. You can use
Drive–to–Drive communications to connect any FORCE drive
with either a Standard Adapter or a PLC Communications
Adapter Board.
•
Drive C is a 1336 FORCE drive with a PLC Communications
Adapter Board. Channel A of Drive C is in adapter mode.
•
Adapter D uses a 1794–ASB module to adapt the RIO image via
blue hose to FLEX I/O. In this example, two words of image are
used with the 24V DC FLEX I/O modules to increase discrete
I/O.
•
Adapter E suggests use with either a 1771–ASB module or a
PLC–5 in an adapter mode for a 1/4 rack of image.
•
Drive F uses a remote I/O communications (GD1) module as an
adapter to convert the RIO image to SCANport parameters when
interfacing with a FORCE drive with a standard adapter or a 1336
PLUS drive.
