Rockwell Automation 1336T PLC Comm. Adapter, Series B, FRN 2.xx-3.xx - Manual (Page 234)

8–8
Publication 1336 FORCE–5.13 –– September, 1998
Fault text and
code:
Suggested action: Description:
Fault
type:
Adapter Config
Err
24026
Soft
The PLC Communications
Adapter Board has detected that
board DIP switch settings do
not match values stored in
BRAM.
Verify the DIP switch settings and
execute a BRAM store to save the new
settings.
No AP LM Exists
25023
Hard
The PLC Communications
Adapter Board has detected that
a language module has not been
installed on the PLC
Communications Adapter
Board.
Reset the drive. If the fault persists,
replace the language module.
SP Pt1 Timeout
26038
Soft,
warning,
or none The device connected to Port 1
of SCANport has been
disconnected.
None
SP Pt2 Timeout
26039
Soft,
warning,
or none The device connected to Port 2
of SCANport has been
disconnected.
None
SP Pt3 Timeout
26040
Soft,
warning,
or none The device connected to Port 3
of SCANport has been
disconnected.
None
SP Pt4 Timeout
26041
Soft,
warning,
or none The device connected to Port 4
of SCANport has been
disconnected.
None
SP Pt5 Timeout
26042
Soft,
warning,
or none The device connected to Port 5
of SCANport has been
disconnected.
None
SP Comm Fault
26043
Hard
The integrity check on the board
hardware has failed.
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
SP Offline
26057
Soft,
warning,
or none
Excessive Communication
errors.
Check SCANport connection/cables.
Replace terminal. If fault persists,
replace PLC. Comm Adapter Brd.
HW Malfunction
34001
Hard
The integrity check on the board
hardware has failed.
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
HW Malfunction
34002
Hard
The integrity check on the board
hardware has failed.
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
HW Malfunction
34003
Hard
The integrity check on the board
hardware has failed.
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
HW Malfunction
34004
Hard
The integrity check on the board
hardware has failed.
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
