322 Channel A Remote I/O Input 0
[ChA RIOA In 0] –– adapter mode
[ChA RIOS In 0] –– scanner mode
ChA RIOx In 0 contains the first word or data group
from the PLC controller output image table. The
RIO scanner transfers the data to the drive every
rack scan. The PLC Communications Adapter
Board can use this value directly. Other drive
functions can use this value through a configuration
link.
Parameter Number 322➀
Parameter Type Read Only, Source
Display Units / Drive Units None
Factory Default None
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – Channel A
➀ This parameter is not available if you set up channel A for DH+. Availability also
depends on the selected rack size.
Note: All eight words are displayed regardless of the rack size. Only the number of words corresponding to the rack size and protocol
(with or without block transfer) are functional.
323 Channel A Remote I/O Input 1
[ChA RIOA In 1] –– adapter mode
[ChA RIOS In 1] –– scanner mode
ChA RIOx In 1 contains the second word or data
group from the PLC controller output image table.
The RIO scanner transfers the data to the drive
every rack scan. The PLC Communications Adapter
Board can use this value directly. Other drive
functions can use this value through a configuration
link.
Parameter Number 323➀
Parameter Type Read Only, Source
Display Units / Drive Units None
Factory Default None
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – Channel A
➀ This parameter is not available if you set up channel A for DH+. Availability also
depends on the selected rack size.
Note: All eight words are displayed regardless of the rack size. Only the number of words corresponding to the rack size and protocol
(with or without block transfer) are functional.
324 Channel A Remote I/O Input 2
[ChA RIOA In 2] –– adapter mode
[ChA RIOS In 2] –– scanner mode
ChA RIOx In 2 contains the third word or data group
from the PLC controller output image table. The
RIO scanner transfers the data to the drive every
rack scan. The PLC Communications Adapter
Board can use this value directly. Other drive
functions can use this value through a configuration
link.
Parameter Number 324➀
Parameter Type Read Only, Source
Display Units / Drive Units None
Factory Default None
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – Channel A
➀ This parameter is not available if you set up channel A for DH+. Availability also
depends on the selected rack size.
Note: All eight words are displayed regardless of the rack size. Only the number of words corresponding to the rack size and protocol
(with or without block transfer) are functional.
