6–32
Publication 1336 FORCE–5.13 –– September, 1998
395 Analog Input 2 Scale
[Analog In 2 Scale]
Analog In 2 Scale determines the scale factor or
gain for the Analog In 2 value. A +10V dc signal
applied to Analog In 2 at TB21 is converted to a
+2048 digital value used by the 1336 FORCE.
Before the digital value is displayed or transferred to
the drive, the scale factor is applied allowing an
effective digital range of
±
32767 (16 x 2048). The
absolute digital value is clamped at 32767.
Scale Factor Drive Units
1 2048
2 4096
4 8192
16 32767
Parameter Number 395
Parameter Type Read/Write, Non–Linkable Sink
Display Units / Drive Units
±
32767
Factory Default +1
Minimum Value –16
Maximum Value +16
File – Group Communications I/O – Analog Input
396 Analog Input 3 Offset
[Analog In 3 Offset]
Analog In 3 Offset determines the offset applied to
the raw Analog In 3 values before the scale factor is
applied. This allows you to shift the range of the
analog input.
Parameter Number 396
Parameter Type Read/Write, Non–Linkable Sink
Display Units / Drive Units
±
4096
Factory Default 0
Minimum Value –20 Volts
Maximum Value +20 Volts
File – Group Communications I/O – Analog Input
397 Analog Input 3 Scale
[Analog In 3 Scale]
Analog In 3 Scale determines the scale factor or
gain for the Analog In 3 value. A +10V dc signal
applied to Analog In 3 at TB21 is converted to a
+2048 digital value used by the 1336 FORCE.
Before the digital value is displayed or transferred to
the drive, the scale factor is applied allowing an
effective digital range of
±
32767 (16 x 2048). The
absolute digital value is clamped at 32767.
Scale Factor Drive Units
1 2048
2 4096
4 8192
16 32767
Parameter Number 397
Parameter Type Read/Write, Non–Linkable Sink
Display Units / Drive Units
±
32767
Factory Default +1
Minimum Value –16
Maximum Value +16
File – Group Communications I/O – Analog Input
398 Analog Input 4 Offset
[Analog In 4 Offset]
Analog In 4 Offset determines the offset applied to
the raw Analog In 4 values before the scale factor is
applied. This allows you to shift the range of the
analog input.
Parameter Number 398
Parameter Type Read/Write, Non–Linkable Sink
Display Units / Drive Units
±
4096
Factory Default 0
Minimum Value –20 Volts
Maximum Value +20 Volts
File – Group Communications I/O – Analog Input
