359 Channel B Remote I/O Output 0
[ChB RIOA Out 0] –– adapter mode
[ChB RIOS Out 0] –– scanner mode
ChB RIOx Out 0 contains the first word or data
group to the PLC controller input image table. The
data is transferred to the PLC controller every rack
scan. The PLC Communications Adapter Board can
provide this value directly. Other drive functions can
provide this value through a configuration link.
Parameter Number 359➀
Parameter Type Read/Write, Sink
Display Units / Drive Units None
Factory Default None
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – Channel B
➀ This parameter is not available if you set up channel B for DH+. Availability also
depends on the selected rack size.
NOTE: If Channel B (A) is configured as RIOA w/Block transfer, this parameter is
defined as a source parameter to prevent accidental linking and unpredictal Block
Transfer behavior.
Note: All eight words are displayed regardless of the rack size. Only the number of words corresponding to the rack size and protocol
(with or without block transfer) are functional.
360 Channel B Remote I/O Output 1
[ChB RIOA Out 1] –– adapter mode
[ChB RIOS Out 1] –– scanner mode
ChB RIOx Out 1 contains the second word or data
group to the PLC controller input image table. The
data is transferred to the PLC controller every rack
scan. The PLC Communications Adapter Board can
provide this value directly. Other drive functions can
provide this value through a configuration link.
Parameter Number 360➀
Parameter Type Read/Write, Sink
Display Units / Drive Units None
Factory Default None
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – Channel B
➀ This parameter is not available if you set up channel B for DH+. Availability also
depends on the selected rack size.
Note: All eight words are displayed regardless of the rack size. Only the number of words corresponding to the rack size and protocol
(with or without block transfer) are functional.
361 Channel B Remote I/O Output 2
[ChB RIOA Out 2] –– adapter mode
[ChB RIOS Out 2] –– scanner mode
ChB RIOx Out 2 contains the third word or data
group to the PLC controller input image table. The
data is transferred to the PLC controller every rack
scan. The PLC Communications Adapter Board can
provide this value directly. Other drive functions can
provide this value through a configuration link.
Parameter Number 361➀
Parameter Type Read/Write, Sink
Display Units / Drive Units None
Factory Default None
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – Channel B
➀ This parameter is not available if you set up channel B for DH+. Availability also
depends on the selected rack size.
Note: All eight words are displayed regardless of the rack size. Only the number of words corresponding to the rack size and protocol
(with or without block transfer) are functional.
362 Channel B Remote I/O Output 3
[ChB RIOA Out 3] –– adapter mode
[ChB RIOS Out 3] –– scanner mode
ChB RIOx Out 3 contains the fourth word or data
group to the PLC controller input image table. The
data is transferred to the PLC controller every rack
scan. The PLC Communications Adapter Board can
provide this value directly. Other drive functions can
provide this value through a configuration link.
Parameter Number 362➀
Parameter Type Read/Write, Sink
Display Units / Drive Units None
Factory Default None
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – Channel B
➀ This parameter is not available if you set up channel B for DH+. Availability also
depends on the selected rack size.
Note: All eight words are displayed regardless of the rack size. Only the number of words corresponding to the rack size and protocol
(with or without block transfer) are functional.
