7–6
Publication 1336 FORCE–5.13 –– September, 1998
The Continuous Parameter Value Read function reads a continuous
list of parameters beginning with the starting parameter number.
You define the number of parameters to be read.
PLC Block Transfer Instruction Data
BTW instruction length: 4 words
BTR instruction length: 5-64 words
Message Length
4
Header
Word 1 Header
Word 1
PLC Decimal Value
1
PLC Decimal Value
1 –– Message OK
-32767 –– Message Error
Number of Parameter
Values to Read
Starting Parameter
Number
Number of Parameter
Values to Read
Starting Parameter
Number
•
•
•
•
Data
Word 64
Message Structure
Header
Word 2
Data
Word 3
Data
Word 4
Header
Word 2
Data
Word 3
Data
Word 4
Data
Word 5
Data
Word 6
Data
Word 7
Value Number 1 or
Status Word
Value Number 2 or
Status Word
Value Number 3 or
Status Word
Value Number 60 or
Status Word
0
PLC Request –– Block Transfer Write
Drive Response –– Block Transfer Read
Message Operation
The Continuous Parameter Value Read function specified in the
BTW reads a consecutive group of parameter values from the device,
beginning with the starting parameter number defined in word 4 of
the BTW message. Word 3 of the BTW message defines the number
of parameters to be read. The values return in the BTR response,
beginning with word 5 of the message.
If an error has occurred in reading any of the values, the BTR returns
a status word with a negative value instead of the parameter value.
Parameter Read
Continuous Parameter Value
Read
