439 Channel B Warning Status
[ChB Warn Sts]
ChB Warn Sts lists the current warning conditions at
channel B of the PLC Communications Adapter
Board. This is only present if channel B is defined to
be either RIO adapter or RIO scanner.
Parameter Number 439
Parameter Type Read Only, Source
Display Units / Drive Units Bits
Factory Default 0
Minimum Value 0
Maximum Value 7 (adapter) or 15 (scanner)
File – Group Diagnostics – Fault Select/Status
Communications I/O – Fault Select/Status
When RIO adapter is used:
Enums
Bit 2 Bit 1 Bit 0 Enums Warning
Res/Pgm/Test ChB Res/Pgm/Test (Flt 36024)
Comm Loss ChB Comm Loss (Flt 36022)
Rack Inhibit Rack Inhibit (Flt 36025)
When RIO scanner is used:
Enums
Bit 3 Bit 2 Bit 1 Bit 0 Enums Warning
Rck Flt Grp0 ChB G0 Rack Flt (Flt 36031)
Rck Flt Grp2 ChB G2 Rack Flt (Flt 36032)
Rck Flt Grp4 ChB G4 Rack Flt (Flt 36033)
Rck Flt Grp6 ChB G6 Rack Flt (Flt 36034)
440 SCANport Fault Selection
[SP Fault Sel]
SP Fault Sel indicates which ports will cause a drive
soft fault on loss of communications.
Parameter Number 440
Parameter Type Read Only, Source
Display Units / Drive Units Bits
Factory Default 0011 1110
Minimum Value 0000 0000
Maximum Value 0011 1110
File – Group Diagnostics – Fault Select/Status
Communications I/O – Fault Select/Status
Enums
Bit 5 Bit 4 Bit 3 Bit 2 Bit 1
Enums Fault
Port 1 SP Pt1 Timeout (Flt 26038)
Port 2 SP Pt2 Timeout (Flt 26039)
Port 3 SP Pt3 Timeout (Flt 26040)
Port 4 SP Pt4 Timeout (Flt 26041)
Port 5 SP Pt5 Timeout (Flt 26042)
441 SCANport Warning Selection
[SP Warn Sel]
SP Warn Sel indicates which ports will cause a drive
warning on loss of communications.
Parameter Number 441
Parameter Type Read Only, Source
Display Units / Drive Units Bits
Factory Default 0011 1110
Minimum Value 0000 0000
Maximum Value 0011 1110
File – Group Diagnostics – Fault Select/Status
Communications I/O – Fault Select/Status
Enums
Bit 5 Bit 4 Bit 3 Bit 2 Bit 1
Enums Warning
Port 1 SP Pt1 Timeout (Flt 26038)
Port 2 SP Pt2 Timeout (Flt 26039)
Port 3 SP Pt3 Timeout (Flt 26040)
Port 4 SP Pt4 Timeout (Flt 26041)
Port 5 SP Pt5 Timeout (Flt 26042)
