8–6
Publication 1336 FORCE–5.13 –– September, 1998
PLC Communications Adapter Board fault and warning codes are
five character decimal numbers that have the following format:
S A XXX
Source Designator
0 = Main Board Velocity Processor
1 = Main Board Current Processor
2 = Adapter Processor
3 = PLC Interface Board Processor
4 = Reserved
5 = Reserved
Area Designator
0 = General
1 = Motor
2 = Inverter
3 =Motor Control
4 = Reserved Adapter
5 = External Device
6 = Communications
7 = Reserved
8 = Reserved
9 = Converter/Brake
Internal Fault Code
S A X X X
Both HIM and GPT LCD displays indicate a fault or warning by
showing the adapter code and fault text. Fault text may be up to 16
characters in length.
The following are the fault codes.
Fault text and
code:
Fault
type:
Description: Suggested action:
Faults Cleared
24000
None
This entry in the fault or
warning queue is displayed
when you request a clear fault
command.
None
Adpt BRAM
Cksm
24009
Soft
There is a discrepancy between
the calculated checksum and the
saved checksum for the adapter
data.
Reset the drive. If the fault persists:
1. Execute a BRAM recall.
2. Execute a BRAM store.
3. Reset the drive.
4. Clear the faults.
When you are done with these steps,
verify all parameter values.
Fault Code Descriptions
Fault Displays
