Rockwell Automation 1336T PLC Comm. Adapter, Series B, FRN 2.xx-3.xx User Manual
Page 265
10–13
Publication 1336 FORCE–5.13 –– September, 1998
DIP Switches U3 (Channel A) or U5 (Channel B)
DIP Switches U2 (Channel A) or U4 (Channel B)
RIO Rack Address
30
Off
On
On
Off
Off
Off
31
Off
On
On
Off
Off
On
32
Off
On
On
Off
On
Off
33
Off
On
On
Off
On
On
34
Off
On
On
On
Off
Off
35
Off
On
On
On
Off
On
36
Off
On
On
On
On
Off
37
Off
On
On
On
On
On
40
On
Off
Off
Off
Off
Off
41
On
Off
Off
Off
Off
On
42
On
Off
Off
Off
On
Off
43
On
Off
Off
Off
On
On
44
On
Off
Off
On
Off
Off
45
On
Off
Off
On
Off
On
46
On
Off
Off
On
On
Off
47
On
Off
Off
On
On
On
50
On
Off
On
Off
Off
Off
51
On
Off
On
Off
Off
On
52
On
Off
On
Off
On
Off
53
On
Off
On
Off
On
On
54
On
Off
On
On
Off
Off
55
On
Off
On
On
Off
On
56
On
Off
On
On
On
Off
57
On
Off
On
On
On
On
60
On
On
Off
Off
Off
Off
61
On
On
Off
Off
Off
On
62
On
On
Off
Off
On
Off
63
On
On
Off
Off
On
On
64
On
On
Off
On
Off
Off
65
On
On
Off
On
Off
On
66
On
On
Off
On
On
Off
67
On
On
Off
On
On
On
70
On
On
On
Off
Off
Off
71
On
On
On
Off
Off
On
72
On
On
On
Off
On
Off
73
On
On
On
Off
On
On
74
On
On
On
On
Off
Off
75
On
On
On
On
Off
On
76
On
On
On
On
On
Off
77
On
On
On
On
On
On
