7–18
Publication 1336 FORCE–5.13 –– September, 1998
The Fault Clear/Reset message activates one of several fault queue
related functions shown in the message request.
PLC Block Transfer Instruction Data
BTW instruction length: 4 words
BTR instruction length: 4 words
Message Length
4
Header
Word 1 Header
Word 1
PLC Decimal Value
-30976
Not Used
PLC Decimal Value
1792 –– Message OK
0
-30976 –– Message Error
0
Fault Command
Clear Fault
Clear Fault Queue
Drive Reset
EE Command Value
00
01
02
03
Status Word
Message Request
Message Structure
Header
Word 2
Header
Word 3
Data
Word 4
Header
Word 2
Data
Word 3
Data
Word 4
0
PLC Request –– Block Transfer Write
Drive Response –– Block Transfer Read
Message Operation
The Fault Clear/Reset function specified in the BTW sends a fault
handling request to the drive.
•
A Clear Fault Request clears the last fault that occurred and
makes the drive available to run.
•
A Clear Fault Queue clears the entire fault buffer.
•
A Drive Reset resets the drive and clears any parameters or links
not saved. Parameter information stored in EEPROM is written to
RAM.
If an error has occurred in the block transfer, word 2 of the BTR
returns a value of -30976.
Fault Queue
Fault Clear/Reset
