6–36
Publication 1336 FORCE–5.13 –– September, 1998
411 Jog Mask
[Jog Mask]
Jog Mask controls which ports can issue a jog
command.
Parameter Number 411
Parameter Type Read/Write, Non–Linkable Sink
Display Units / Drive Units Bits
Factory Default 0
Minimum Value 0
Maximum Value 0FE Hex
File – Group Communications I/O – SCANport Masks
Enums Bit 1 = Port 1 Bit 2 = Port 2 Bit 3 = Port 3 Bit 4 = Port 4
Bit 5 = Port 5 Bit 6 = Channel A Bit 7 = Channel B
412 Reference Mask
[Ref Mask]
Ref Mask controls which ports can select an
alternate reference or preset speed.
Parameter Number 412
Parameter Type Read/Write, Non–Linkable Sink
Display Units / Drive Units Bits
Factory Default 0
Minimum Value 0
Maximum Value 0FE Hex
File – Group Communication I/O – SCANport Masks
Enums Bit 1 = Port 1 Bit 2 = Port 2 Bit 3 = Port 3 Bit 4 = Port 4
Bit 5 = Port 5 Bit 6 = Channel A Bit 7 = Channel B
413 Clear Fault Mask
[Clr Fault Mask]
Clr Fault Mask controls which ports can generate a
clear fault command.
Parameter Number 413
Parameter Type Read/Write, Non–Linkable Sink
Display Units / Drive Units Bits
Factory Default 0
Minimum Value 0
Maximum Value 0FE Hex
File – Group Communications I/O – SCANport Masks
Enums Bit 1 = Port 1 Bit 2 = Port 2 Bit 3 = Port 3 Bit 4 = Port 4
Bit 5 = Port 5 Bit 6 = Channel A Bit 7 = Channel B
414 Reset Drive Mask
[Reset Drive Mask]
Reset Drive Mask controls which ports can reset a
fault.
Parameter Number 414
Parameter Type Read/Write, Non–Linkable Sink
Display Units / Drive Units Bits
Factory Default 0
Minimum Value 0
Maximum Value 0FE Hex
File – Group Communication I/O – SCANport Masks
Enums Bit 1 = Port 1 Bit 2 = Port 2 Bit 3 = Port 3 Bit 4 = Port 4
Bit 5 = Port 5 Bit 6 = Channel A Bit 7 = Channel B
415 Local Mask
[Local Mask]
Local Mask controls which ports are allowed to take
exclusive control of drive logic commands except
Stop. (Stop is accepted from any device regardless
of who has control.) You can only take exclusive
local control while the drive is stopped.
Parameter Number 415
Parameter Type Read/Write, Non–Linkable Sink
Display Units / Drive Units Bits
Factory Default 0
Minimum Value 0
Maximum Value 0FE Hex
File – Group Communications I/O – SCANport Owners
Enums Bit 1 = Port 1 Bit 2 = Port 2 Bit 3 = Port 3 Bit 4 = Port 4
Bit 5 = Port 5 Bit 6 = Channel A Bit 7 = Channel B
