8–9
Publication 1336 FORCE–5.13 –– September, 1998
Fault text and
code:
Suggested action: Description:
Fault
type:
HW Malfunction
34005
Hard
The integrity check on the board
hardware has failed.
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
ChA Rack Config
34006
Hard
The DIP switch settings indicate
that more than one full rack
should be scanned. This fault is
specific to RIO scanner.
Verify the DIP switch settings for
channel A. RIO scanner can only scan
one full logical rack per channel.
ChB Rack Config
34007
Hard
The DIP switch settings indicate
that more than one full rack
should be scanned. This fault is
specific to RIO scanner.
Verify the DIP switch settings for
channel B. RIO scanner can only scan
one full logical rack per channel.
ChA Module
Group
34012
Hard
The PLC Communications
Adapter Board has detected a
channel A module group that is
not valid for the selected rack
size.
Check parameter 303 (DIP switch
ChA) and verify the DIP switch
settings:
Channel A High sw3 sw4
Module 0 Off Off
Module 2 Off On
Module 4 On Off
Module 6 On On
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
ChB Module
Group
34013
Hard
The PLC Communications
Adapter Board has detected a
channel B module group that is
not valid for the selected rack
size.
Check parameter 304 (DIP switch
ChB) and verify the DIP switch
settings:
Channel B High sw3 sw4
Module 0 Off Off
Module 2 Off On
Module 4 On Off
Module 6 On On
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
