8–7
Publication 1336 FORCE–5.13 –– September, 1998
Fault text and
code:
Suggested action: Description:
Fault
type:
Drv Types Differ
24010
Soft
There is a discrepancy between
the drive type on the base driver
board and the parameter 220
and 221 values in BRAM.
Reset the drive. If the fault persists:
1. Execute a BRAM recall.
2. Execute a BRAM store.
3. Reset the drive.
4. Clear the faults.
When you are done with these steps,
verify all parameter values.
I11 Drive Type
24011
Hard
The drive type code in Serial E2
on the base driver board is not a
valid code per the language
module table.
Replace the base driver board.
Main BRAM
Cksm
24012
Soft
There is a discrepancy between
the calculated checksum and the
saved checksum for the main
control board.
Reset the drive. If the fault persists:
1. Execute a BRAM recall.
2. Execute a BRAM store.
3. Reset the drive.
4. Clear the faults.
When you are done with these steps,
verify all parameter values.
SW Malfunction
24013
Hard
The integrity check on the board
software has failed.
Reset the drive. If the fault persists,
you may have to replace either the
PLC Communications Adapter Board
or the main control board.
SW Malfunction
24014
Hard
The integrity check on the board
software has failed.
Reset the drive. If the fault persists,
you may have to replace either the
PLC Communications Adapter Board
or the main control board.
SW Malfunction
24015
Hard
The integrity check on the board
software has failed.
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
SW Malfunction
24016
Hard
The integrity check on the board
software has failed.
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
SW Malfunction
24017
Hard
The integrity check on the board
software has failed.
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
SW Malfunction
24018
Hard
The integrity check on the board
software has failed.
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
AP SW/LM Rev
Err
24025
Soft
There is a PLC
Communications Adapter Board
software/language module
mismatch.
Verify the board software and language
module versions with Allen–Bradley.
