6–14
Publication 1336 FORCE–5.13 –– September, 1998
317 Data Input B2
[Data In B2]
Data In B2 contains the fourth image word from the
SCANport output image table.
Parameter Number 317
Parameter Type Read Only, Source
Display Units / Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – SCANport I/O
318 Data Input C1
[Data In C1]
Data In C1 contains the fifth image word from the
SCANport output image table.
Parameter Number 318
Parameter Type Read Only, Source
Display Units / Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – SCANport I/O
319 Data Input C2
[Data In C2]
Data In C2 contains the sixth image word from the
SCANport output image table.
Parameter Number 319
Parameter Type Read Only, Source
Display Units / Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – SCANport I/O
320 Data Input D1
[Data In D1]
Data In D1 contains the seventh image word from
the SCANport output image table.
Parameter Number 320
Parameter Type Read Only, Source
Display Units / Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – SCANport I/O
321 Data Input D2
[Data In D2]
Data In D2 contains the eighth image word from the
SCANport output image table.
Parameter Number 321
Parameter Type Read Only, Source
Display Units / Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – SCANport I/O
