10–10
Publication 1336 FORCE–5.13 –– September, 1998
The following charts are designed to be used as reference for setting
and checking your DIP switches. Refer to the appropriate chart for
the protocol you are using.
RIO Adapter With or Without Block Transfer
DIP Switches U2 (Channel A) or U4 (Channel B)
SW1 SW2 SW3 SW4 SW5 SW6 SW7 SW8
DIP Switches U3 (Channel A) or U5 (Channel B)
SW1 SW2 SW3 SW4 SW5 SW6 SW7 SW8
Protocol
RIO w/oBlock Transfer Off Off
RIO w/Block Transfer Off On
Baud Rate
57.6K Off Off
115.2K Off On
230.4K On either
RIO Rack Size
1/4 Off Off
1/2 Off On
3/4 On Off
Full On On
Not Last/Last
Last On
Not Last Off
Redundant
Yes On
No Off
RIO Starting Group
0 Off Off
2 Off On
4 On Off
6 On On
RIO Rack Address
01 Off Off Off Off Off On
02 Off Off Off Off On Off
03 Off Off Off Off On On
04 Off Off Off On Off Off
05 Off Off Off On Off On
06 Off Off Off On On Off
07 Off Off Off On On On
10 Off Off On Off Off Off
11 Off Off On Off Off On
12 Off Off On Off On Off
13 Off Off On Off On On
14 Off Off On On Off Off
15 Off Off On On Off On
16 Off Off On On On Off
17 Off Off On On On On
RIO Rack Address
PLC Communications
Adapter Board DIP Switch
Settings
