348 Data Output C2
[Data Out C2]
Data Out C2 contains the sixth image word from the
SCANport input image table.
Parameter Number 348
Parameter Type Read/Write, Sink
Display Units / Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – SCANport I/O
349 Data Output D1
[Data Out D1]
Data Out D1 contains the seventh image word from
the SCANport input image table.
Parameter Number 349
Parameter Type Read/Write, Sink
Display Units / Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – SCANport I/O
350 Data Output D2
[Data Out D2]
Data Out D2 contains the eighth image word from
the SCANport input image table.
Parameter Number 350
Parameter Type Read/Write, Sink
Display Units / Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – SCANport I/O
351 Channel A Remote I/O Output 0
[ChA RIOA Out 0] –– adapter mode
[ChA/B RIOA Out0] –– adapter mode with redundancy
[ChA RIOS Out 0] –– scanner mode
ChA RIOx Out 0 contains the first word or data
group to the PLC controller input image table. The
data is transferred to the PLC controller every rack
scan. The PLC Communications Adapter Board can
provide this value directly. Other drive functions can
provide this value through a configuration link.
Parameter Number 351➀
Parameter Type Read/Write, Sink
Display Units / Drive Units None
Factory Default None
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – Channel A
➀ This parameter is not available if you set up channel A for DH+. Availability also
depends on the selected rack size.
NOTE:If Channel A (B) is configured as RIOA w/Block transfer, this parameter is
defined as a source parameter to prevent accidental linking and unpredictable Block
Transfer behavior.
Note: All eight words are displayed regardless of the rack size. Only the number of words corresponding to the rack size and protocol
(with or without block transfer) are functional.
352 Channel A Remote I/O Output 1
[ChA RIOA Out 1] –– adapter mode
[ChA/B RIOA Out1] –– adapter mode with redundancy
[ChA RIOS Out 1] –– scanner mode
ChA RIOx Out 1 contains the second word or data
group to the PLC controller input image table. The
data is transferred to the PLC controller every rack
scan. The PLC Communications Adapter Board can
provide this value directly. Other drive functions can
provide this value through a configuration link.
Parameter Number 352➀
Parameter Type Read/Write, Sink
Display Units / Drive Units None
Factory Default None
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – Channel A
➀ This parameter is not available if you set up channel A for DH+. Availability also
depends on the selected rack size.
Note: All eight words are displayed regardless of the rack size. Only the number of words corresponding to the rack size and protocol
(with or without block transfer) are functional.
