8–10
Publication 1336 FORCE–5.13 –– September, 1998
Fault text and
code:
Suggested action: Description:
Fault
type:
Redund Rack Size
34014
Hard
The PLC Communications
Adapter Board has detected
different rack sizes for channels
A and B when RIO with
redundancy was selected.
Check parameters 303 and 304 (DIP
Switch ChA and DIP Switch ChB).
Verify the DIP switch settings. Both
channels must have the same rack size.
Channels A/B LOW sw5 sw6
1/4 rack Off Off
1/2 rack Off On
3/4 rack On Off
Full rack On On
Note: Full racks can only have the
Last/Not Last switch set to Off.
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
Redund Diff Prot
34015
Hard
The PLC Communications
Adapter Board has detected
redundant operation has been
called for, but channel A is not
configured for the RIO protocol.
Check parameters 303 and 304 (DIP
Switch ChA and DIP Switch ChB).
Verify the DIP switch settings. Both
channels must be configured for the
RIO protocol when using the
redundant mode.
Channel A LOW sw8
Non–redundant Off
Redundant On
Channel B LOW sw1 sw2
RIO w/o Blk Trans Off Off
RIO w/ Blk Trans Off On
DH+ On Off
RIO scanner On On
If the fault persists, replace the PLC
Communications Adapter Board.
SW Malfunction
34016
Hard
The integrity check on the board
software has failed.
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
ChA Dup
Nodeaddr
36019
Soft
The PLC Communications
Adapter Board has detected a
duplicate channel A DH+ node
address.
Check parameter 303 (DIP Switch
ChA) and refer to the table in Chapter
2 to verify the DIP switch settings.
Reset the drive. If the fault persists,
replace the PLC Communications
Adapter Board.
