6–44
Publication 1336 FORCE–5.13 –– September, 1998
437 Channel A Warning Status
[ChA Warn Sts]
ChA Warn Sts lists the current warning conditions at
channel A of the PLC Communications Adapter
Board. This is only present if channel A is defined to
be either RIO adapter or RIO scanner.
Parameter Number 437
Parameter Type Read Only, Source
Display Units / Drive Units Bits
Factory Default 0
Minimum Value 0
Maximum Value 7 (adapter) or 15 (scanner)
File – Group Diagnostics – Fault Select/Status
Communications I/O – Fault Select/Status
When RIO adapter is used:
Enums
Bit 2 Bit 1 Bit 0 Enums Warning
Res/Pgm/Test ChA Res/Pgm/Test (Flt 36023)
Comm Loss ChA Comm Loss (Flt 36021)
Rack Inhibit Rack Inhibit (Flt 36025)
When RIO scanner is used:
Enums
Bit 3 Bit 2 Bit 1 Bit 0 Enums Warning
Rck Flt Grp0 ChA G0 Rack Flt (Flt 36027)
Rck Flt Grp2 ChA G2 Rack Flt (Flt 36028)
Rck Flt Grp4 ChA G4 Rack Flt (Flt 36029)
Rck Flt Grp6 ChA G6 Rack Flt (Flt 36030)
438 Channel B Fault Status
[ChB Fault Sts]
ChB Fault Sts lists the current fault conditions at
channel B of the PLC Communications Adapter
Board. This is only present if channel B is defined to
be either RIO adapter or RIO scanner.
Parameter Number 438
Parameter Type Read Only, Source
Display Units / Drive Units Bits
Factory Default 0
Minimum Value 0
Maximum Value 7 (adapter) or 15 (scanner)
File – Group Diagnostics – Fault Select/Status
Communications I/O – Fault Select/Status
When RIO adapter is used:
Enums
Bit 2 Bit 1 Bit 0 Enums Fault
Res/Pgm/Test ChB Res/Pgm/Test (Flt 36024)
Comm Loss ChB Comm Loss (Flt 36022)
Rack Inhibit Rack Inhibit (Flt 36025)
When RIO scanner is used:
Enums
Bit 3 Bit 2 Bit 1 Bit 0 Enums Fault
Rck Flt Grp0 ChB G0 Rack Flt (Flt 36031)
Rck Flt Grp2 ChB G2 Rack Flt (Flt 36032)
Rck Flt Grp4 ChB G4 Rack Flt (Flt 36033)
Rck Flt Grp6 ChB G6 Rack Flt (Flt 36034)
