6–35
Publication 1336 FORCE–5.13 –– September, 1998
407 Analog Output 4 Scale
[Analog Out 4 Scale]
Analog Out 4 Scale determines the scale factor or
gain for the Analog In 4 value. A +2048 value
corresponds to a +10V output signal at TB21. The
value sent (linked) to Analog Out 4 is scaled by the
corresponding scale parameter before it is offset and
converted to an analog signal.
Scale Factor Drive Units
1 32767
1/2 16383
1/4 8192
1/16 2048
Parameter Number 407
Parameter Type Read/Write, Non–Linkable Sink
Display Units / Drive Units
±
32767
Factory Default +1
Minimum Value –1
Maximum Value +1
File – Group Communication I/O – Analog Output
408 Port Enable
[Port Enable]
Port Enable indicates which ports can accept
commands listed in parameters 409 through 415.
Parameter Number 408
Parameter Type Read/Write, Non–Linkable Sink
Display Units / Drive Units Bits
Factory Default 0
Minimum Value 0
Maximum Value 0FE Hex
File – Group Communications I/O – SCANport Masks
Enums Bit 1 = Port 1 Bit 2 = Port 2 Bit 3 = Port 3 Bit 4 = Port 4
Bit 5 = Port 5 Bit 6 = Channel A Bit 7 = Channel B
409 Direction Mask
[Dir Mask]
Dir Mask controls which ports can issue
forward/reverse commands.
Parameter Number 409
Parameter Type Read/Write, Non–Linkable Sink
Display Units / Drive Units Bits
Factory Default 0
Minimum Value 0
Maximum Value 0FE Hex
File – Group Communications I/O – SCANport Masks
Enums Bit 1 = Port 1 Bit 2 = Port 2 Bit 3 = Port 3 Bit 4 = Port 4
Bit 5 = Port 5 Bit 6 = Channel A Bit 7 = Channel B
410 Start Mask
[Start Mask]
Start Mask controls which ports can issue a start
command.
Parameter Number 410
Parameter Type Read/Write, Non–Linkable Sink
Display Units / Drive Units Bits
Factory Default 0
Minimum Value 0
Maximum Value 0FE Hex
File – Group Communications I/O – SCANport Masks
Enums Bit 1 = Port 1 Bit 2 = Port 2 Bit 3 = Port 3 Bit 4 = Port 4
Bit 5 = Port 5 Bit 6 = Channel A Bit 7 = Channel B
