5 Motor control (MCTRL)
5.5 Sensorless vector control (SLVC)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.5.1 Parameterisation dialog

Proceed as follows to open the dialog for parameterising the motor control:
1. »Engineer« Go to the Project view and select the 8400 BaseLine D controller.
2. Go to Workspace and change to the Application parameters tab.
3. Select the motor control "4: SLVC: Vector control" from the Overview dialog level in the
Motor control ( C006 ) list field.
4. Click the Motor control vector button to change to the Overview  Motor control vector di-
alog box.
• This dialog level lists shows all relevant parameters in a parameter list.
Short overview of the relevant parameters:
5.5.2 Speed control with torque limitation
A speed setpoint is selected and the drive system is operated in a speed-controlled manner.
Parameter Info
C006 Selection of the motor control
 "4: SLVC: Vector control"
C011 Reference speed
C018 Switching frequency
C021 Slip compensation
C022 Imax in motor mode
C023 Imax in generator mode
C050 Speed setpoint
C057 Maximum torque
C058 Output frequency
C081 Rated motor power
C084 Motor stator resistance
C085 Motor stator leakage inductance
C087 Rated motor speed
C088 Rated motor current
C089 Rated motor frequency
C090 Rated motor voltage
C091 Motor cosine phi
C092 Motor magnetising inductance
C095 Motor magnetising current
C097 Rated motor torque
C105 Deceleration time - quick stop
C909/1 Max. pos. speed
C909/2 Max. neg. speed
C910/1 Max. pos. output frequency
C910/2 Max. neg. output frequency
Highlighted in grey = display parameter
