8 Diagnostics & error management
8.7 Error messages of the operating system
156
Lenze · 8400 BaseLine D · Reference manual · DMS 5.5 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.7.3 Short overview (A-Z)
The table below contains all error messages of the controller operating system in alphabetical order.

Tip!
If you click the cross-reference in the first column, "Error number", you get to the detailed
description of the respective error message in the subsequent " Cause & possible remedies "
chapter. ( 157)

Note!
For the sake of legibility, the Logbook and C165 display the error number with the follo-
wing syntax:
[Error type].[Error subject area no.].[.].[Error ID]
In this documentation, "xx", a wildcard, stands for the error type since it is configurable
for many error messages.
Error number Error message Response
(Lenze setting)
can be set in CAN Emergency
Error Code
 xx.0125.00001 An01: AIN1_I < 4 mA Fault C598/1 0xF000
 xx.0145.00001 dF01: Internal error 01 Fault -
 xx.0145.00002 dF02: Internal error 02 Fault -
 xx.0145.00003 dF03: Internal error 03 Fault -
 xx.0145.00004 dF04: Internal error 04 Fault -
 xx.0145.00005 dF05: Internal error 05 Fault -
 xx.0145.00006 dF06: Internal error 06 Fault -
 xx.0145.00007 dF07: Internal error 07 Fault -
 xx.0145.00008 dF08: Internal error 08 Fault -
 xx.0145.00009 dF09: Internal error 09 Fault -
 xx.0145.00010 dF10: Internal error 10 Fault -
 xx.0400.00105 dH69: Adjustment data error Fault - 0x5530
 xx.0123.00057 ID1: Motor data identification error WarningLocked - 0xF000
 xx.0123.00015 LU: DC bus undervoltage Trouble C600/1 0x3100
 xx.0123.00016 OC1: Power section - short circuit Fault - 0x2000
 xx.0123.00017 OC2: Power section - earth fault Fault - 0x2000
 xx.0119.00050 OC5: Ixt overload WarningLocked C604 0x2000
 xx.0123.00105 OC6: I2xt motor overload WarningLocked C606 0x2000
 xx.0119.00052 OC9: Ixt overload - shutdown limit Fault - 0x2000
 xx.0123.00065 OC12: I2xt brake resistance overload Fault - 0xF000
 xx.0119.00001 OH: Heatsink overtemperature Fault - 0x4000
 xx.0123.00014 OU: DC bus overvoltage Trouble - 0x3100
 xx.0144.00001 PS01: No memory module Warning - 0x6300
 xx.0144.00002 PS02: Par. set invalid Fault - 0x6300
 xx.0144.00003 PS03: Par. set device invalid Fault - 0x6300
 xx.0144.00004 PS04: Par. set device incompatible Fault - 0x6300
 xx.0144.00031 PS31: Ident. error Fault - 0x6300
 xx.0111.00002 Su02: One mains phase is missing WarningLocked C565 0x3000
 xx.0980.00000 US01: User error 1 Fault C581/1 0x6200
 xx.0981.00000 US02: User error 2 Fault C581/2 0x6200
