7
Drive application
7.1
Parameterisation dialog
126
Lenze · 8400 BaseLine D · Reference manual · DMS 5.5 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Configuration parameters for analog setpoints:
Display parameter
bRLQCcw
(
)
0: Not connected
Activate counter-clockwise rotation (fail-safe)
bSetSpeedCcw
(
)
14: DigIn_bIn4
(DI4)
Change of direction of rotation
bJogSpeed1
(
)
11: DigIn_bIn1
(DI1)
Selection of fixed setpoints (JOG setpoints)
bJogSpeed2
(
)
12: DigIn_bIn2
(DI2)
bPIDEnableInfluenceRamp
(
)
1: C_bTrue
: Activate ramp for influencing factor
bPIDOff
(
)
0: Not connected
: Switch off I component
bCInh
(
)
1: C_bTrue
bFailReset
(
)
15: DigIn_CInh
(RFR)
bSetQuickstop
(
)
0: Not connected
Enable quick stop (QSP)
bSetDCBrake
(
)
13: DigIn_bIn3
(DI3)
Manual DC-injection braking (DCB)
Parameter
Selection of signal source
(Lenze setting)
for setpoint selection:
nMainSetValue_a
(
)
10: AIn1_Out
(Analog input 1)
Main setpoint
• 100 % ≡ reference speed (
nPIDSetValue_a
(
)
0: Not connected
: Sensor setpoint or process setpoint for ope-
rating mode 2
nPIDVpAdapt_a
(
)
1: C_nPos100_a
(100%)
: Adaptation of the gain Vp set in
in per-
cent
nPIDActValue_a
(
)
0: Not connected
: Actual speed value or actual sensor value
(actual process value)
nPIDInfluence_a
(
)
1: C_nPos100_a
(100%)
: Limitation of the influencing factor in per-
cent
Parameter
Info
nIn_a
(
)
Input value of motor potentiometer
nNSet_a
(
)
Input value of setpoint generator
nOut_a
(
)
Output value of setpoint generator
nSpeedSetValue_a
(
)
Speed setpoint for motor control
nSet_a
(
)
Sensor setpoint or process setpoint for operating mode 2
nAdapt_a
(
)
Adaptation of the gain Vp set in
in percent
nAct_a
(
)
Speed or actual sensor value (actual process value)
Parameter
Selection of signal source
(Lenze setting)
for control signal:
