9 Parameter reference
9.2 Parameter list | C00308
202
Lenze · 8400 BaseLine D · Reference manual · DMS 5.5 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00308
C00309
C00443
Parameter | Name:
C00308 | Activation of internal features
Data type: UNSIGNED_16
Index: 24267
d
= 5ECB
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00309 | Delay time
Data type: UNSIGNED_16
Index: 24266
d
= 5ECA
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00443 | DIx: Level
Data type: UNSIGNED_16
Index: 24132
d
= 5E44
h
Bit-coded display of the level of the digital inputs
 Digital terminals
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 DI1 Bit set = HIGH level
Bit 1 DI2
Bit 2 DI3
Bit 3 DI4
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 CINH
Subcodes Info
C00443/1 DIx: Terminal level
C00443/2 DIx: Output level
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
