5 Motor control (MCTRL)
5.1 Motor selection/Motor data
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

How to carry out automatic motor parameter identification:
1. Inhibit the controller if it is enabled, e.g. via the C002/16 device command or a LOW signal
at the X4/RFR terminal.
2. Wait until the drive is at standstill.
3. Transfer the nameplate data to the following codes:
• C081 : Rated motor power
• C087 : Rated motor speed
• C088 : Rated motor current (according to the connection method /)
• C089 : Rated motor frequency (according to the connection method /)
• C090 : Rated motor voltage (according to the connection method /)
• C091 : Motor cos ϕ
4. Start motor parameter identification via the C002/23 device command.
5. Enable the controller again.
• Motor parameter identification starts.
• The progress of the identification can be seen in
C002/23 .
• The identification is completed if the "0: Off / ready" message is displayed in C002/23 .
6. Inhibit controller again.
