2 Introduction: Parameterising the controller
2.3 Internal Keypad
20
Lenze · 8400 BaseLine D · Reference manual · DMS 5.5 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
2.3.3 Display messages
Display Meaning
An01 constant Analog input 1: Current < 4 mA
bF blinking Identification error.
• Drive ID stored in EMP does not match the drive ID stored in the
controller.
br flashes during the hold time
of DC braking
DC braking is executed.
CAL blinking Identification is executed.
The operation is not yet enabled.
CAL / Err alternatively blinking Identification is not ready to start.
• C088 , C089 or C090 is 0.
CAL / Stop alternatively blinking Identification is ready to start.
CL constant Clamp: The current limit value selected in C022 has been reached.
dec constant Deceleration is temporarily suspended because of higher bus volta-
ge
dF01 ... dF10 constant Internal error
dH69 constant Adjustment data error
Err blinking A wrong password has been entered.
FCL constant The current limit value selected in C022 has been exceeded.
FSt constant "Flying restart" function is executed.
ID1 constant Motor data identification error
LU constant DC bus undervoltage
OC1 constant Power section - short circuit
OC12 constant I2xt brake resistor overload
OC2 constant Power section - earth fault
OC5 constant Ixt overload
OC6 constant I2xt motor overload
OC9 constant Ixt overload - shutdown limit
OH constant Heatsink overtemperature
OU constant DC bus overvoltage
PASS 0.5 seconds on Password protection is active
PS01 constant No memory module inserted
PS02 constant Parameter set is invalid
PS03 constant Parameter set device invalid
PS31 constant Incompatible or unknown HW components have been found.
Su02 constant One mains phase is missing
US01 / US02 constant User error 1 / user error 2
