Lenze 8400 BaseLine D - Manual (Page 83)

Lenze · 8400 BaseLine D · Reference manual · DMS 5.5 EN · 01/2014 · TD05
83
5 Motor control (MCTRL)
5.4 V/f characteristic control (VFCplus)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.4.3 Optimise control behaviour
The V/f characteristic control (VFCplus) is generally ready for operation. It can be adapted subse-
quently by adapting the characteristic and/or the drive behaviour.
Adapting characteristic
For the linear and quadratic characteristic, it is also possible to match its curve to different load pro-
files or motors by adapting the V/f base frequency ( C015 ) and the V
min
-boost ( C016 ) .
 Adapting the V/f base frequency ( 84)
 Adapting the Vmin boost ( 85)
Adapting drive behaviour
• Limitation of the maximum current by a current limitation controller (e.g. to prevent the motor
from stalling or to limit to the maximally permissible motor current) . Optimising the Imax
controller ( 86)
• Adaptation of the field frequency by a load-dependent slip compensation (improved speed ac-
curacy for systems without feedback)
