9 Parameter reference
9.2 Parameter list | C00517
206
Lenze · 8400 BaseLine D · Reference manual · DMS 5.5 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00517
C00565
Parameter | Name:
C00517 | User menu
Data type: INTEGER_32
Index: 24058
d
= 5DFA
h
When a system is installed, parameters must be changed time and again until the system runs satisfactorily. The
user menu of a device serves to create a selection of frequently used parameters to be able to access and change
these parameters quickly.
• For setting "0" no entry is displayed in the user menu.
Setting range (min. value | unit | max. value)
0 994
Subcodes Lenze setting Info
C00517/1 51 C00051 : Display of actual speed value
C00517/2 53 C00053 : Display of DC-bus voltage
C00517/3 54 C00054 : Display of motor current
C00517/4 61 C00061 : Display of heatsink temperature
C00517/5 137 C00137 : Display of device state
C00517/6 0 User menu: entry 6
C00517/7 0 User menu: entry 7
C00517/8 11 C00011 : Reference speed
C00517/9 39 C00039/1 : Fixed setpoint 1
C00039/2 : Fixed setpoint 2
C00039/3 : Fixed setpoint 3
C00517/10 0 User menu: entry 10
C00517/11 12 C00012 : Acceleration time main setpoint
C00517/12 13 C00013 : Deceleration time main setpoint
C00517/13 15 C00015 : V/f base frequency
C00517/14 16 C00016 : Vmin boost
C00517/15 22 C00022 : Imax in motor mode
C00517/16 120 C00120 : Motor overload threshold (I 2 xt)
C00517/17 87 C00087 : Rated motor speed
C00517/18 99 C00099 : Display of firmware version
C00517/19 0 User menu: entry 19
C00517/20 0 User menu: entry 20
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00565 | Resp. to mains phase failure
Data type: UNSIGNED_8
Index: 24010
d
= 5DCA
h
Response to the failure of mains phases
Selection list
(Lenze setting printed in bold)
0 No Reaction
1 Fault
4 WarningLocked
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
