Lenze · 8400 BaseLine D · Reference manual · DMS 5.5 EN · 01/2014 · TD05
173
9 Parameter reference
9.2 Parameter list | C00003
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00003
C00006
Parameter | Name:
C00003 | Status of last device command
Data type: UNSIGNED_8
Index: 24572
d
= 5FFC
h
Status of the device command carried out last ( C00002 ).
Note:
Before switching off the supply voltage after carrying out a device command, check whether the device command
has been carried out successfully via the status display!
 Drive control (DCTRL) : Device commands
Selection list (read only) Info
0 Successful Device command has been carried out successfully.
1 Command unknown Device command is implausible or not known in the sys-
tem.
2 No access Access for requested device command is not approved.
3 Time-out Device command could not be processed in the defined
time (time-out).
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00006 | Motor control
Data type: UNSIGNED_8
Index: 24569
d
= 5FF9
h
Selection of the motor control mode
 Motor control (MCTRL) : Select control mode
Selection list (Lenze setting printed in bold) Info
4 SLVC: Vector control This control type is used for sensorless vector control of
an asynchronous motor.
• The control type requires motor parameters to be set
as exactly as possible!
 Sensorless vector control
6 VFCplus: V/f linear This control type is used for the speed control of an asyn-
chronous motor via a linear V/f characteristic and is the
simplest control type.
• For setting the V/f characteristic, only the rated fre-
quency ( C00089 ) and the rated voltage ( C00090 ) of
the motor have to be entered.
 V/f characteristic control
8 VFCplus: V/f quadr This control type is used for speed control of an asynchro-
nous motor via a square-law V/f characteristic.
• For setting the V/f characteristic, only the rated fre-
quency ( C00089 ) and the rated voltage ( C00090 ) of
the motor have to be entered.
 V/f characteristic control
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
