3 Commissioning
3.3 Commissioning with integrated keypad
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.3.2 Parameterise drive/application
The menu -2- of the integrated keypad contains all basic parameters to commission the drive/appli-
cation "actuating drive speed" quickly and easily for a terminal control. When you set these parame-
ters to suitable and sensible values, the controller can be operated properly.
More detailed information on the drive application:
 Drive application ( 122)
 Interface description ( 128)
 Setting parameters (short overview) ( 133)
 Pre-assignment of the drive application ( 134)
 Terminal assignment of the control modes ( 137)
Parameter Lenze setting Info
Value Unit
C002/1
Load Lenze setting
0: Off / ready Reset all parameters to the Lenze setting which are sa-
ved in the controller firmware.
C007
Select control mode
10: Terminals 0  Terminal assignment of the control modes ( 137)
C011
Reference speed
1500 rpm All speed setpoint selections are provided in % and al-
ways refer to the reference speed set in C011 .
The motor reference speed is given on the motor name-
plate.
C012
Acceleration time - main setpoint
2.0 s The setpoint is led via a ramp function generator with li-
near characteristic. The ramp function generator con-
verts setpoint step-changes at the input into a ramp.
 L_NSet_1 ( 230)
C013
Deceleration time - main setpoint
2.0 s
C015
V/f base frequency
50.0 Hz  Adapting the V/f base frequency ( 84)
C016
Vmin boost
0.0 %  Adapting the Vmin boost ( 85)
C022
Current limit (in motor mode)
47.00 A  Optimising the Imax controller ( 86)
C087
Rated motor speed
1460 rpm  Motor selection/Motor data ( 66)
C089
Rated motor frequency
50 Hz
C039/1
Fixed setpoint 1
40.0 % A fixed setpoint for the setpoint generator can be acti-
vated instead of the main setpoint via the digital inputs
DI1 and DI2.
• The fixed setpoints are selected in [%] based on the
reference speed ( C011 ).
 L_NSet_1 ( 230)
C039/2
Fixed setpoint 2
60.0 %
C039/3
Fixed setpoint 3
80.0 %
C051
Actual speed value
- rpm
C054
Current motor current
- A
Highlighted in grey = display parameter
